Horizon 1.0 FS MTB Blue
Horizon 1.0 FS MTB Blue
Click & Collect Customers: Your chosen store will phone you within 24 hours to confirm a collection date based on location of stock and your chosen store.
Australia’s best value full suspension Mountain Bike - the Horizon 1.0 FS - is an instant confidence booster so you can rip faster on more difficult trails.
Full suspension mountain bikes soak up the bumps so your tyres stay planted to the trail instead of being bounced out of contact. Yes, it’s more comfortable, but the real benefit comes from the increased control when pushing your riding.
The Horizon 1.0 FS 29er is a versatile cross-country/trail bike that benefits from the high end technology driving the advance of Mountain Bike riding.
The Horizon 1.0 FS mountain bike frame is a lightweight double-butted 6061 hydroformed alloy with modern trail geometry. The rear suspension is a tried and tested four-bar linkage design which allows the rear to work independently of braking for improved control when flying down a trail. A Suntour XCM 100mm travel suspension fork with hydraulic lock out gives smooth control over broken ground and enough bounce to soak up the hits. Coupled with a Raidon R at the rear, this is a balanced mountain bike tuned for flow.
Tektro M285 Hydraulic Disc brakes deliver reliable power and control in all conditions and when riding at high speeds. This value priced full-suspension 29er mountain bike is made for going fast and the Suntour XCM crankset and Shimano Acera 3 x 9 speed gearing gives plenty of range for steep descents and climbs.
The 29 x 2.1” Kenda Small Block 8 tyres are a proven favourite for all-round trail riding. Fast rolling on hard dirt surfaces and with good contact over a wide area for railing berms at speed.
- Tough and lightweight double-butted 6061 hydroformed aluminium alloy frame with four-bar linkage rear suspension design. Features modern trail/cross-country (XC) geometry for improved trail performance.
- Suntour XCM 100mm travel suspension fork with hydraulic lock-out for efficiency on the climbs and cushion on the descents.
- Raidon R rear suspension for a balanced bike tuned for flow.
- Upgraded Tektro M285 Hydraulic Disc brakes for reliable stopping power and modulation control in the dirt and in the wet.
- Suntour XCM crankset and Shimano Acera 3 x 9 speed gearing for a wide range.
- Finished with lock-on grips and Kenda Small Block Eight tyres.
|Frame||29er dual suspension 6061 alloy hydro formed tubing disc brake specific|
|Forks||Suntour xcm hlo 100mm travel qr|
|Rear Shock||Suntour raidon r hydraulic damping rebound adjust|
|Wheelset / Rim||Alex md19 double wall alloy 32 hole 24.4mm inner width|
|Brakes||Tektro m285 hydraulic|
|Tyres||Kenda small block 8 29 x 2.1”|
|Hubs||Alloy disc specific quick release|
|Freewheel / Cassette||Shimano hg200 11-32t 9 speed|
|Front Derailleur||Shimano acera m3000|
|Rear Derailleur||Shimano acera m3000|
|Handlebars||Double butted alloy 31.8 diameter 700mm wide 9 degree backsweep|
|Stem||Alloy 31.8mm diameter 60mm length|
|Shifters||Shimano acera m3000 3 x 9 speed|
|Bottom Bracket||Vp sealed cartridge|
|Brake Lever||Tektro m285 hydraulic|
|Pedals||Alloy full body mtb|
|Seatpost||Alloy 31.6mm 400mm length|
|Chainset||Suntour xcm 22/32/44t|
|Top tube length||595||615||595||615||595||615|
|Seat tube length||440||490||440||490||440||490|
|Head tube length||110||115||110||115||110||115|
|Seat tube angle||68.5||68.5||68.5||68.5||68.5||68.5|
|Head tube angle||69||69||69||69||69||69|
|Full fork length||515||515||515||515||515||515|
|SMALL||160cm - 167cm||5'2" - 5'5"|
|MEDIUM||167cm - 176cm||5'5" - 5'8"|
|LARGE||176cm - 185cm||5'8" - 6'1"|
|X LARGE||185cm - 195cm||6'1" - 6'4"|
This series of how-to video guides will take you through each step of assembling and tuning your new Bike. Watch the series or choose the tasks you need help with:
Assembly instructions guide
If you prefer to work from step-by-step diagrams, you can use this Assembly Instruction Guide for key points on all basic areas of bike assembly.
Need more assistance?
Please contact Customer Service for friendly expert advice to help you get your bike ready to ride. We welcome your questions as they will help us to improve the instructions we provide in future.
Our Horizon 1.0 FS MTB Blue includes the industry-leading Reid Warranty: lifetime on frame and rigid forks, 2 years on non-consumable parts and a free first service to get you going. Test ride in-store or shop online to enjoy a 30 Day Test Ride to guarantee you get a great deal.
Click and Collect
Buy online and collect in-store from our Melbourne, Brisbane or Perth stores fully assembled by our bike mechanics and ready to ride.
Be advised that your chosen store will phone you within 24 hours of ordering to confirm a collection date based on your availability, the location of stock and your chosen collection store.
Our bikes are shipped in a box 85% assembled and require basic assembly, like turning handlebars and inserting pedals. Check out our Assembly Videos that give instructions on how to do this.
Buy One, Plant One
Since January 2020 we have partnered with Eden Reforestation Projects to donate enough money to pay a local person a fair wage to grow, plant and guard to maturity 1 native tree for every bike we sell.
We've now planted more than 200,000 trees and counting.
- PHPeter H.Verified BuyerI recommend this productAge Range 35 - 44How often you ride RegularlyReasons you ride Fitness, Fun, Outdoors, Family, FriendsRated 5 out of 5 stars11 months agoReid Horizon 1.0
What do I think about the Reid Horizon 1.0.
standing back and looking at the bike standard it looks like a well finished off outfit. Being a budget duel suspension bike.
There are things such as the ability to lock out the rear which is not available and maybe a one by drive train would be a better option than the outdated triple set up the bike comes with. However for a budget bike it ticks the boxes if you want to go out and your not worried about how it’s going to look after a few rides. It will handle everything you throw at it. The frame is solid all be it a little heavier than bikes a few 100 more from online suppliers with budget components where you will get rear lock out and a one by system. The paint is a Matt finish and doesn’t hold up well, it’s easily scratched and chipped. In fact this bike is the second bike as the first frame was scratched from the store before I even rode it so bike was swapped out for a new one. Only to have the drink bottle holder stud twisting in the frame so a new stud had to be fitted, but when the bottom bracket was removed to get the old stud out the frame it was scratched. So covering the frame around the the chain stays is very important. My bike has ride wrap on all the areas where your likely to see chips etc so hopefully the frame can stay in good condition for it’s life with me. The stock tyres are not at all great if you want to smash the down hill trails so upgrading them is a must but if your planning on using it for more…Value for moneyRated 5.0 on a scale of 1 to 5Component qualityRated 3.0 on a scale of 1 to 5
- DMDavid M.Verified BuyerI recommend this productRated 4 out of 5 stars2 years ago4 Stars
Comfortable to ride but will change the gearing system. Great start up option.
- TLTerry L.I recommend this productRated 4 out of 5 stars2 years ago4 Stars
Best value for money dual Suspension money can buy. Love it so far.
