The perfect lightweight entry into road riding, fast commuting or fitness rides for those who prefer a flat-bar configuration. If you're on a budget or just getting started with road riding, the Rapid flat-bar road bike is the way to go.
Built around a proven alloy frame to keep the weight low, with the addition of a steel fork to soak up road vibration.
With a versatile upright road geometry, this is a comfortable bike that affords the rider good visibility when commuting or riding in the city.
The Rapid flat-bar road bike features a flat handlebar for riders who are familiar with this style of bike; or prefer this setup for a more upright position or easier control at slow speeds in traffic.
Striking a balance between performance, reliability and value-for-money requires careful specification choices. Shimano Tourney shifters and derailleurs are unbeatable at this pricepoint and will provide years of faithful service.
Promax Dual-Pivot Caliper Brakes offer great stopping ability. Dual-pivot means that instead of old-fashioned brake calipers that lever off the central bolt, the brakes lever off two separate pivot points, increasing the braking power, feel and control.
To finish this quality value-priced road bike, the Rapid runs on lightweight double-wall alloy rims with Quando quick-release hubs and Kenda 23c road tyres for a fast-rolling ride.
Key Features:
- Flat handlebar for riders who are more familiar with this style of bike or prefer it for city riding.
- Lightweight alloy road bike frame with steel fork to soak up road vibration.
- 14-speed Shimano Tourney shifters and front/rear derailleurs for unbeatable performance and durability at a value price.
-
Double wall alloy rims, Quando quick-release hubs and Kenda 23c tyres for a light, fast-rolling wheelset.
- Reliable control with Promax Dual-Pivot caliper brakes.
- 10.94 kg
Build
| Frame | Alloy |
|---|---|
| Fork | Steel |
| Handlebars | Alloy 560mm 25.4 Barbore |
| Stem | Alloy 1" Quill Stem |
| Pedals | Nylon platform with 9/16" steel axle |
| Saddle | Reid Black Road Saddle |
| Seatpost | Alloy 27.2mm x 250mm |
| Rider Weight Limit | 120kg |
Groupset
| Bottom Bracket | VP Sealed Bearing |
|---|---|
| Chain | KMC Z33 |
| Brakes | Promax Dual-Pivot Caliper Brakes |
| Brake Lever | Promax Alloy |
| Freewheel | Shimano TZ500 7-Speed Freewheel (14-28t) |
| Front Derailleur | Shimano Tourney TZ510 |
| Rear Derailleur | Shimano Tourney TZ500 |
| Shifters | Shimano Tourney TZ500 Stem Mounted |
Wheels
| Wheelset | Double Wall Alloy Lightweight |
|---|---|
| Tyres | Kenda 700 x 23c Road Tyre |
| Front Hubs | Quando Alloy Quick Release |
Extras
| Grips | Ergonomic Rubber Black 125mm |
|---|---|
| Kickstand | Not included |
| Bell | Included |
| Reflectors | Included |
| Mudguards | Not included |
We reserve the right to modify product specifications and details without prior notification.
| Size | Small | Medium | Large | X Large |
|---|---|---|---|---|
| Top Tube Length | 530 | 550 | 573 | 590 |
| Seat Tube Length | 475 | 510 | 545 | 570 |
| Head Tube Length | 140 | 160 | 180 | 200 |
| Seat Tube Angle | 74 | 73 | 73 | 72 |
| Head Tube Angle | 72 | 72 | 72 | 72 |
| RC Length | 420 | 420 | 420 | 420 |
| BB Drop | 72 | 70 | 70 | 70 |
| Fork Offset | 45 | 45 | 45 | 45 |
| Front Centre | 587 | 498 | 609 | 622 |
| Wheelbase | 996 | 1008 | 1020 | 1032 |
| Full Fork Length | 378 | 378 | 378 | 378 |
Length measurements are provided in millimeters and degrees, unless specified otherwise.
| Size | Range (cm) | Range (ft & in) |
|---|---|---|
| Small | 150 - 160 | 4'11" - 5'3" |
| Medium | 160 - 170 | 5'3" - 5'7" |
| Large | 170 - 180 | 5'7" - 5'11" |
| X Large | 180 - 195 | 5'11" - 6'5" |
If you are outside of the size range or unsure of the best fit, give us a call and we'll help get you on the right bike.
| Size | Age | Range (cm) | Range (ft & in) |
|---|---|---|---|
| 12" (Balance) | 2 - 4 | 80 - 100 | 2'6" - 3'1" |
| 16" | 4 - 7 | 100 - 120 | 3'4" - 4'0" |
| 20" | 7 - 9 | 120 - 135 | 4'0" - 4'5" |
| 24" | 9 - 11 | 135 - 145 | 4'5" - 4'9" |
If you are outside of the size range or unsure of the right fit for you, give us a call or come in and visit your local store to talk about your best options.
Explore our series of how-to video guides designed to walk you through every stage of assembling and fine-tuning your new Rapid Flatbar Bike Black. Whether you watch the entire series or focus on specific tasks, we've got you covered. Our dedicated Customer Service team is here to offer expert advice and ensure your bike is ready for the road.
How to: Unbox Your Bike
Learn how to safely unpack and assemble your new bicycle.
How to: Install the Seatpost
Step-by-step guide on fitting and securing the seatpost on your bike frame.
How to: Inflate Tires
Properly inflate your bicycle tires to the recommended pressure for a smooth ride.
How to: Install Quill Stem Handlebars
Install and align quill stem handlebars securely.
How to: Install Caliper-Style Brakes
Set up and install caliper brakes for effective stopping power.
How to: Install Pedals
Correctly attach pedals to the crank arms of your bike.
How to: Install Quick-Release Wheels
Attach and secure wheels with quick-release mechanisms.
How to: Adjust a Rear Derailleur
Adjust the rear derailleur for smooth gear shifting.
How to: Adjust the Front Derailleur
Make adjustments to the front derailleur for precise gear changes.
How to: Quickly Fit Your Bike
Tips for a basic bike fit to ensure comfort and efficiency.
Planning to assemble at home? Remember to install the pedals with care. Make sure to align them square and gently tighten to avoid stripping the threads.
Description
The perfect lightweight entry into road riding, fast commuting or fitness rides for those who prefer a flat-bar configuration. If you're on a budget or just getting started with road riding, the Rapid flat-bar road bike is the way to go.
Built around a proven alloy frame to keep the weight low, with the addition of a steel fork to soak up road vibration.
With a versatile upright road geometry, this is a comfortable bike that affords the rider good visibility when commuting or riding in the city.
The Rapid flat-bar road bike features a flat handlebar for riders who are familiar with this style of bike; or prefer this setup for a more upright position or easier control at slow speeds in traffic.
Striking a balance between performance, reliability and value-for-money requires careful specification choices. Shimano Tourney shifters and derailleurs are unbeatable at this pricepoint and will provide years of faithful service.
Promax Dual-Pivot Caliper Brakes offer great stopping ability. Dual-pivot means that instead of old-fashioned brake calipers that lever off the central bolt, the brakes lever off two separate pivot points, increasing the braking power, feel and control.
To finish this quality value-priced road bike, the Rapid runs on lightweight double-wall alloy rims with Quando quick-release hubs and Kenda 23c road tyres for a fast-rolling ride.
Key Features:
- Flat handlebar for riders who are more familiar with this style of bike or prefer it for city riding.
- Lightweight alloy road bike frame with steel fork to soak up road vibration.
- 14-speed Shimano Tourney shifters and front/rear derailleurs for unbeatable performance and durability at a value price.
-
Double wall alloy rims, Quando quick-release hubs and Kenda 23c tyres for a light, fast-rolling wheelset.
- Reliable control with Promax Dual-Pivot caliper brakes.
- 10.94 kg
Specifications
Build
| Frame | Alloy |
|---|---|
| Fork | Steel |
| Handlebars | Alloy 560mm 25.4 Barbore |
| Stem | Alloy 1" Quill Stem |
| Pedals | Nylon platform with 9/16" steel axle |
| Saddle | Reid Black Road Saddle |
| Seatpost | Alloy 27.2mm x 250mm |
| Rider Weight Limit | 120kg |
Groupset
| Bottom Bracket | VP Sealed Bearing |
|---|---|
| Chain | KMC Z33 |
| Brakes | Promax Dual-Pivot Caliper Brakes |
| Brake Lever | Promax Alloy |
| Freewheel | Shimano TZ500 7-Speed Freewheel (14-28t) |
| Front Derailleur | Shimano Tourney TZ510 |
| Rear Derailleur | Shimano Tourney TZ500 |
| Shifters | Shimano Tourney TZ500 Stem Mounted |
Wheels
| Wheelset | Double Wall Alloy Lightweight |
|---|---|
| Tyres | Kenda 700 x 23c Road Tyre |
| Front Hubs | Quando Alloy Quick Release |
Extras
| Grips | Ergonomic Rubber Black 125mm |
|---|---|
| Kickstand | Not included |
| Bell | Included |
| Reflectors | Included |
| Mudguards | Not included |
We reserve the right to modify product specifications and details without prior notification.
Geometry
| Size | Small | Medium | Large | X Large |
|---|---|---|---|---|
| Top Tube Length | 530 | 550 | 573 | 590 |
| Seat Tube Length | 475 | 510 | 545 | 570 |
| Head Tube Length | 140 | 160 | 180 | 200 |
| Seat Tube Angle | 74 | 73 | 73 | 72 |
| Head Tube Angle | 72 | 72 | 72 | 72 |
| RC Length | 420 | 420 | 420 | 420 |
| BB Drop | 72 | 70 | 70 | 70 |
| Fork Offset | 45 | 45 | 45 | 45 |
| Front Centre | 587 | 498 | 609 | 622 |
| Wheelbase | 996 | 1008 | 1020 | 1032 |
| Full Fork Length | 378 | 378 | 378 | 378 |
Length measurements are provided in millimeters and degrees, unless specified otherwise.
Size Guide
| Size | Range (cm) | Range (ft & in) |
|---|---|---|
| Small | 150 - 160 | 4'11" - 5'3" |
| Medium | 160 - 170 | 5'3" - 5'7" |
| Large | 170 - 180 | 5'7" - 5'11" |
| X Large | 180 - 195 | 5'11" - 6'5" |
If you are outside of the size range or unsure of the best fit, give us a call and we'll help get you on the right bike.
Assembly
Explore our series of how-to video guides designed to walk you through every stage of assembling and fine-tuning your new Rapid Flatbar Bike Black. Whether you watch the entire series or focus on specific tasks, we've got you covered. Our dedicated Customer Service team is here to offer expert advice and ensure your bike is ready for the road.
How to: Unbox Your Bike
Learn how to safely unpack and assemble your new bicycle.
How to: Install the Seatpost
Step-by-step guide on fitting and securing the seatpost on your bike frame.
How to: Inflate Tires
Properly inflate your bicycle tires to the recommended pressure for a smooth ride.
How to: Install Quill Stem Handlebars
Install and align quill stem handlebars securely.
How to: Install Caliper-Style Brakes
Set up and install caliper brakes for effective stopping power.
How to: Install Pedals
Correctly attach pedals to the crank arms of your bike.
How to: Install Quick-Release Wheels
Attach and secure wheels with quick-release mechanisms.
How to: Adjust a Rear Derailleur
Adjust the rear derailleur for smooth gear shifting.
How to: Adjust the Front Derailleur
Make adjustments to the front derailleur for precise gear changes.
How to: Quickly Fit Your Bike
Tips for a basic bike fit to ensure comfort and efficiency.
Planning to assemble at home? Remember to install the pedals with care. Make sure to align them square and gently tighten to avoid stripping the threads.
