Upgraded 2024 model. Featuring the all-new Shimano CUES gearing and improved Tektro Hydraulic Disc brakes, Australia’s best value 1x10 MTB just got better. A simple, rugged, and progressive 29er hardtail MTB for riders looking to experience Mountain Biking and develop their trial skills while having a blast doing it!
The Tract 3 MY24 sees the introduction of the much anticipated Shimano CUES gearing in 1x10. Riding with one cog and no front derailleur is the preferred setup for Mountain Biking. 10 gears at the back give you plenty of range, but the simplicity upfront means reduced weight, more clearance over rocks and logs, and one less lever to think about when pushing yourself.
Designed for riders who are looking for a quality entry to the world of Mountain Biking on proper trails, singletrack, and XC; the Tract range brings the most up-to-date standards in MTB geometry and specification at this price point.
Light, fast, and designed for a confidence-inspiring ride, the Tract hydroformed double-butted alloy frame features slacker angles and a low-slung top tube for manoeuvrability and control in corners and descents. Geometry and spec choices on this bike were made specifically for performance in the dirt.
The lightweight and easily adjustable SR Suntour XCM30 100mm travel suspension fork gives smooth control over broken ground and enough bounce to soak up the hits. The hydraulic lock-out feature will be appreciated by riders looking to maximize efficiency on big climbs or long hauls over flat ground.
29-inch wheels are the modern standard for Mountain Biking and getting on a 29er has never been as accessible as the Tract. 29 x 2.25” Compass MTB tyres coupled with durable double-wall alloy rims will hold the ground for a fast and responsive ride.
Stopping power and control are delivered by trusted Tektro Hydraulic Disc Brakes with 160mm rotors. Hydraulics offers more power with less lever force required than other systems, which gives better modulation and control in all riding conditions.
The Reid Tract range is the best value way to get into Mountain Biking on a progressive, trail-ready 29er MTB that is built to take the demands of the sport. The Tract is a real-deal MTB built from the ground up for singletrack, jumps, rocks, technical climbs, and fast descents.
Key Features:
- Tough and lightweight double-butted 6061 hydroformed aluminium alloy frame with internal gear cable routing and tapered headset for increased stiffness (cornering precision and better feedback from the trail).
- Modern trail/cross-country (XC) progressive geometry with slacker angles and low standover for confidence-inspiring off-road performance.
- Lightweight SR Suntour XCM30 100mm travel suspension fork with a hydraulic lock-out for efficiency on the climbs and cushion on the descents.
- Tektro Hydraulic Disc brakes with 160mm rotors for stopping power and modulation control in the dirt and in the wet.
- Trail performance with the cutting-edge Shimano CUES 1 x 10 gearing. The ideal setup for lightweight simplicity and clearance over obstacles like rocks and logs.
- Upgraded drivetrain includes new threaded bottom bracket and narrow/wide chainring design with anti chain-drop device for improved retention.
Frame | Hydroformed 6061 aluminium alloy with internal gear cabling |
Forks | Sr suntour xcm30 100mm travel suspension with hydraulic lock out and fixed rebound damping |
Wheelset / Rim | Double wall alloy 29\\ 32h |
Brakes | Tektro hydraulic disc 160mm rotors |
Tyres | 29 x 2.25″ compass mtb |
Hubs | Alloy mtb 32h 6-bolt disc specific with quick release |
Freewheel / Cassette | 10-speed (11-48t) |
Front Derailleur | N/a |
Rear Derailleur | Shimano cues 10-speed |
Handlebars | Reid double butted alloy 31.8 700mm |
Stem | Reid mtb threadless alloy oversize 31.8mm |
Shifters | Shimano cues 10-speed |
Bottom Bracket | Sealed bearing threaded |
Brake Lever | Tektro hydraulic disc |
Pedals | Alloy mtb |
Chain | Kmc x10 |
Grips | Reid mtb lock-on |
Saddle | Reid mtb |
Seatpost | Reid alloy 27.2 x 350mm |
Chainset | Prowheel narrow/wide design with anti chain drop device |
Kickstand | N/a |
Small | Medium | Large | Extra Large | |
Top tube length | 560 | 608 | 628 | 651 |
Seat tube length | 381 | 432 | 483 | 533 |
Head tube length | 120 | 120 | 120 | 130 |
Seat tube angle | 74 | 74 | 74 | 74 |
Head tube angle | 68 | 68 | 68 | 68 |
RC length | 440 | 440 | 440 | 440 |
BB drop | 65 | 65 | 65 | 65 |
Fork offset | 46 | 46 | 46 | 46 |
Front centre | 661 | 708 | 729 | 753 |
Wheelbase | 1093 | 1142 | 1168 | 1191 |
Full fork length | 515 | 515 | 515 | 515 |
CM | FEET | |
SMALL | 160cm - 167cm | 5'2" - 5'5" |
MEDIUM | 167cm - 178cm | 5'5" - 5'10" |
LARGE | 178cm - 185cm | 5'10" - 6'1" |
EXTRA LARGE | 185cm - 193cm | 6'1" - 6'4" |
This series of how-to video guides will take you through each step of assembling and tuning your new Bike. Watch the series or choose the tasks you need help with:
Assembly instructions guide
If you prefer to work from step-by-step diagrams, you can use this Assembly Instruction Guide for key points on all basic areas of bike assembly.
Need more assistance?
Please contact Customer Service for friendly expert advice to help you get your bike ready to ride. We welcome your questions as they will help us to improve the instructions we provide in future.
Our Tract 3 Mountain Bike MY24 Grey includes the industry-leading Reid Warranty: lifetime on frame and rigid forks, 2 years on non-consumable parts and a free tune-up to get you going. Test ride in-store or shop online to enjoy a 30 Day Test Ride to guarantee you get a great deal.
Click and Collect
Buy online and collect in-store from our Richmond (Melbourne) flagship store fully assembled by our bike mechanics and ready to ride.
Be advised that your chosen store will phone you within 24 hours of ordering to confirm a collection date based on your availability, the location of stock and your chosen collection store.
Home Delivery
Our bikes are shipped in a box 85% assembled and require basic assembly, like turning handlebars and inserting pedals. Check out our Assembly Videos that give instructions on how to do this.
Buy One, Plant One
Since January 2020 we have partnered with Eden Reforestation Projects to donate enough money to pay a local person a fair wage to grow, plant and guard to maturity 1 native tree for every bike we sell.
We've now planted more than 200,000 trees and counting.
