Looking for a tough, versatile bike at an affordable price? Our ever popular MTB Sport has just had a major update to deliver an even more confident all-rounder for exploring off-road trails or everyday rides through the city; all whilst maintaining that unbeatable value price!
Built on a lightweight 6061 aluminium frame, the MTB Sport features comfortable all-rounder geometry to suit whatever terrain you find yourself riding. Coupled with an efficient 80mm travel suspension fork, this bike offers a comfortable and controlled ride on roads, paths and off-road trails.
The latest Shimano Tourney 21-speed gearing gives you all the smooth-shifting range you’ll need to enjoy fast descents or navigating tricky off-road climbs.
Finished with easy-to-adjust V-brakes and hard-wearing alloy parts, the MTB Sport is a Mountain Bike you can rely on to get you there and back again.
Key Features:
- Lightweight 6061 aluminium alloy MTB frame with comfortable upright geometry suitable for all-round riding.
- Shimano Tourney TY300 21-speed gearing for plenty of smooth shifting range.
- Efficient 80mm travel suspension fork for comfort and control over broken ground.
- Alloy V-Brakes for reliable stopping power and easy maintenance.
- 26" x 2.1 MTB tyres, comfortable MTB saddle and contact points.
Build
| Frame | 6061 aluminium alloy |
|---|---|
| Fork | Alloy suspension 27.5" 80mm travel |
| Handlebars | Reid oversize alloy |
| Stem | Reid MTB 1-1/8″ threadless alloy, oversize |
| Pedals | Resin platform, 9/16″ steel axle |
| Saddle | Reid MTB |
| Seatpost | Reid alloy 31.6mm micro adjust |
Groupset
| Bottom Bracket | Sealed bearing |
|---|---|
| Chain | KMC Z33 |
| Brake Lever | Alloy V Brake |
| Freewheel | Shimano TZ500 14-28T Freewheel |
| Front Derailleur | Shimano TZ30 |
| Rear Derailleur | Shimano TY300 |
| Shifters | LTWOO 7 speed trigger |
| Front Brakes | Alloy V Brakes |
| Rear Brakes | Alloy V Brakes |
| Chain Set | Steel 170mm crankset 24/34/42T |
Wheels
| Wheelset | Reid double wall alloy |
|---|---|
| Tyres | 27.5 x 2.1″ MTB |
| Front Hubs | Alloy MTB QR |
Extras
| Grips | MTB rubber |
|---|
We reserve the right to modify product specifications and details without prior notification.
| Size | S (38) | M (43) | L (48) | XL (53) |
|---|---|---|---|---|
| Top Tube Length | 557 | 587 | 607 | 632 |
| Seat Tube Length | 380 | 430 | 480 | 530 |
| Head Tube Length | 110 | 110 | 120 | 130 |
| Seat Tube Angle | 74 | 74 | 73 | 73 |
| Head Tube Angle | 70.5 | 70.5 | 70.5 | 70.5 |
| RC Length | 435 | 435 | 435 | 435 |
| BB Drop | 48 | 48 | 48 | 48 |
| Fork Offset | 40 | 40 | 40 | 40 |
| Front Centre | 626 | 644 | 665 | 690 |
| Wheelbase | 1057 | 1074 | 1095 | 1121 |
| Full Fork Length | 510 | 510 | 510 | 510 |
| Standover Height | 729 | 765 | 796 | 827 |
Length measurements are provided in millimeters and degrees, unless specified otherwise.
| Size | Range (cm) | Range (ft & in) |
|---|---|---|
| Small | 160 - 167 | 5'3" - 5'6" |
| Medium | 167 - 174 | 5'6" - 5'9" |
| Large | 177 - 185 | 5'10" - 6'1" |
| X Large | 185 - 193 | 6'1" - 6'4" |
If you are outside of the size range or unsure of the best fit, give us a call and we'll help get you on the right bike.
| Size | Age | Range (cm) | Range (ft & in) |
|---|---|---|---|
| 12" (Balance) | 2 - 4 | 80 - 100 | 2'6" - 3'1" |
| 16" | 4 - 7 | 100 - 120 | 3'4" - 4'0" |
| 20" | 7 - 9 | 120 - 135 | 4'0" - 4'5" |
| 24" | 9 - 11 | 135 - 145 | 4'5" - 4'9" |
If you are outside of the size range or unsure of the right fit for you, give us a call or come in and visit your local store to talk about your best options.
Explore our series of how-to video guides designed to walk you through every stage of assembling and fine-tuning your new MTB Sport 27.5" Mountain Bike Black. Whether you watch the entire series or focus on specific tasks, we've got you covered. Our dedicated Customer Service team is here to offer expert advice and ensure your bike is ready for the road.
How to: Unbox Your Bike
Learn how to safely unpack and assemble your new bicycle.
How to: Install the Seatpost
Step-by-step guide on fitting and securing the seatpost on your bike frame.
How to: Inflate Tires
Properly inflate your bicycle tires to the recommended pressure for a smooth ride.
How to: Install a Front Wheel Nut and Axle
Mount the front wheel with proper alignment and secure it in place.
How to: Install Pedals
Correctly attach pedals to the crank arms of your bike.
How to: Adjust a Rear Derailleur
Adjust the rear derailleur for smooth gear shifting.
How to: Quickly Fit Your Bike
Tips for a basic bike fit to ensure comfort and efficiency.
How to: Adjust Disc Brakes
Fine-tune and align disc brakes for optimal braking performance.
How to: Adjust the Front Derailleur
Make adjustments to the front derailleur for precise gear changes.
Planning to assemble at home? Remember to install the pedals with care. Make sure to align them square and gently tighten to avoid stripping the threads.
Description
Looking for a tough, versatile bike at an affordable price? Our ever popular MTB Sport has just had a major update to deliver an even more confident all-rounder for exploring off-road trails or everyday rides through the city; all whilst maintaining that unbeatable value price!
Built on a lightweight 6061 aluminium frame, the MTB Sport features comfortable all-rounder geometry to suit whatever terrain you find yourself riding. Coupled with an efficient 80mm travel suspension fork, this bike offers a comfortable and controlled ride on roads, paths and off-road trails.
The latest Shimano Tourney 21-speed gearing gives you all the smooth-shifting range you’ll need to enjoy fast descents or navigating tricky off-road climbs.
Finished with easy-to-adjust V-brakes and hard-wearing alloy parts, the MTB Sport is a Mountain Bike you can rely on to get you there and back again.
Key Features:
- Lightweight 6061 aluminium alloy MTB frame with comfortable upright geometry suitable for all-round riding.
- Shimano Tourney TY300 21-speed gearing for plenty of smooth shifting range.
- Efficient 80mm travel suspension fork for comfort and control over broken ground.
- Alloy V-Brakes for reliable stopping power and easy maintenance.
- 26" x 2.1 MTB tyres, comfortable MTB saddle and contact points.
Specifications
Build
| Frame | 6061 aluminium alloy |
|---|---|
| Fork | Alloy suspension 27.5" 80mm travel |
| Handlebars | Reid oversize alloy |
| Stem | Reid MTB 1-1/8″ threadless alloy, oversize |
| Pedals | Resin platform, 9/16″ steel axle |
| Saddle | Reid MTB |
| Seatpost | Reid alloy 31.6mm micro adjust |
Groupset
| Bottom Bracket | Sealed bearing |
|---|---|
| Chain | KMC Z33 |
| Brake Lever | Alloy V Brake |
| Freewheel | Shimano TZ500 14-28T Freewheel |
| Front Derailleur | Shimano TZ30 |
| Rear Derailleur | Shimano TY300 |
| Shifters | LTWOO 7 speed trigger |
| Front Brakes | Alloy V Brakes |
| Rear Brakes | Alloy V Brakes |
| Chain Set | Steel 170mm crankset 24/34/42T |
Wheels
| Wheelset | Reid double wall alloy |
|---|---|
| Tyres | 27.5 x 2.1″ MTB |
| Front Hubs | Alloy MTB QR |
Extras
| Grips | MTB rubber |
|---|
We reserve the right to modify product specifications and details without prior notification.
Geometry
| Size | S (38) | M (43) | L (48) | XL (53) |
|---|---|---|---|---|
| Top Tube Length | 557 | 587 | 607 | 632 |
| Seat Tube Length | 380 | 430 | 480 | 530 |
| Head Tube Length | 110 | 110 | 120 | 130 |
| Seat Tube Angle | 74 | 74 | 73 | 73 |
| Head Tube Angle | 70.5 | 70.5 | 70.5 | 70.5 |
| RC Length | 435 | 435 | 435 | 435 |
| BB Drop | 48 | 48 | 48 | 48 |
| Fork Offset | 40 | 40 | 40 | 40 |
| Front Centre | 626 | 644 | 665 | 690 |
| Wheelbase | 1057 | 1074 | 1095 | 1121 |
| Full Fork Length | 510 | 510 | 510 | 510 |
| Standover Height | 729 | 765 | 796 | 827 |
Length measurements are provided in millimeters and degrees, unless specified otherwise.
Size Guide
| Size | Range (cm) | Range (ft & in) |
|---|---|---|
| Small | 160 - 167 | 5'3" - 5'6" |
| Medium | 167 - 174 | 5'6" - 5'9" |
| Large | 177 - 185 | 5'10" - 6'1" |
| X Large | 185 - 193 | 6'1" - 6'4" |
If you are outside of the size range or unsure of the best fit, give us a call and we'll help get you on the right bike.
Assembly
Explore our series of how-to video guides designed to walk you through every stage of assembling and fine-tuning your new MTB Sport 27.5" Mountain Bike Black. Whether you watch the entire series or focus on specific tasks, we've got you covered. Our dedicated Customer Service team is here to offer expert advice and ensure your bike is ready for the road.
How to: Unbox Your Bike
Learn how to safely unpack and assemble your new bicycle.
How to: Install the Seatpost
Step-by-step guide on fitting and securing the seatpost on your bike frame.
How to: Inflate Tires
Properly inflate your bicycle tires to the recommended pressure for a smooth ride.
How to: Install a Front Wheel Nut and Axle
Mount the front wheel with proper alignment and secure it in place.
How to: Install Pedals
Correctly attach pedals to the crank arms of your bike.
How to: Adjust a Rear Derailleur
Adjust the rear derailleur for smooth gear shifting.
How to: Quickly Fit Your Bike
Tips for a basic bike fit to ensure comfort and efficiency.
How to: Adjust Disc Brakes
Fine-tune and align disc brakes for optimal braking performance.
How to: Adjust the Front Derailleur
Make adjustments to the front derailleur for precise gear changes.
Planning to assemble at home? Remember to install the pedals with care. Make sure to align them square and gently tighten to avoid stripping the threads.
Our MTB Sport 27.5" Mountain Bike Black includes the industry-leading Reid Warranty: lifetime on frame/rigid forks and 2 years on non-consumable parts. Shop online to enjoy a 30 Day Test Ride to guarantee you get a great deal.
Home Delivery
Our bikes are shipped in a box 85% assembled and require basic assembly, like turning handlebars and inserting pedals. Check out our Assembly Videos that give instructions on how to do this.
Buy One, Plant One
Since January 2020 we have worked with not-for-profit reforestation partners to donate enough money to pay a local person a fair wage to grow, plant and guard to maturity 1 native tree for every bike we sell.
We've now planted more than 395,000 trees and counting.
- Reviews
- Questions
Excellent Value
Excellent quality for the price, along with good service.
